Lenovo ThinkCentre M60q Chromebox Mini PC Intel® Core™ i5 i5-1235U 8 GB DDR4-SDRAM 128 GB SSD ChromeOS Black - 12C6000BUS

"""Lenovo ThinkCentre M60q Chromebox. Processor family: Intel\u00ae Core\u2122 i5, Processor model: i5-1235U. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 3200 MHz. Total storage capacity: 128 GB, Storage media: SSD. On-board graphics card model: Intel Iris Xe Graphics. Wi-Fi. Operating system installed: ChromeOS. Power supply: 90 W. Chassis type: Mini PC. Product type: Mini PC. Weight: 1.07 kg. Product colour: Black"

Processor

Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	12th gen Intel® Core™ i5
Processor model	i5-1235U
Processor cores	10
Performance cores	2
Efficient cores	8
Efficient-core Max Turbo Frequency	3.3 GHz
Performance-core Max Turbo Frequency	4.4 GHz
Processor boost frequency	4.4 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Processor threads	12
Processor base power	15 W
Maximum turbo power	55 W

Memory

Internal memory	8 GB
Maximum internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
Memory slots	2x SO-DIMM
Memory clock speed	3200 MHz
Memory channels	Dual-channel

Storage

Card reader integrated	No
Total storage capacity	128 GB
Storage media	SSD
Optical drive type	No
Number of storage drives installed	1
Total SSDs capacity	128 GB
Number of SSDs installed	1
SSD capacity	128 GB
SSD interface	PCI Express 3.0
NVMe	Yes
SSD form factor	M.2

Graphics

Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics

Network

Ethernet LAN	Yes
Ethernet LAN data rates	1000,100 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Antenna type	2x2
Bluetooth	Yes
Bluetooth version	5.1

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI ports quantity	2
HDMI version	2.1
DisplayPorts quantity	1
DisplayPort version	1.4
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes

Design

Chassis type	Mini PC
Volume	1 L
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black

Performance

Motherboard chipset	Intel SoC
Audio chip	Realtek ALC5682I
Audio system	High Definition Audio
Built-in speaker(s)	No
Product type	Mini PC

Software

Operating system installed

ChromeOS

Power

Power supply

90 W

Operational conditions

Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m

Certificates

Certification

MIL-STD-810H

Sustainability

Sustainability certificates

ENERGY STAR, EPEAT Gold

Weight & dimensions

Width	178 mm
Depth	182 mm
Height	34 mm
Weight	1.07 kg
Package width	140 mm
Package depth	485 mm
Package height	270 mm
Package weight	2.95 kg

Packaging content

Display included	No
Mouse included	Yes
Keyboard included	Yes
