Lenovo ThinkCentre M90q Gen 5 Intel® Core™ i5 i5-14500 16 GB DDR5-SDRAM 256 GB SSD Windows 11 Pro Mini PC Black - 12TH000YUS

Performance-Driven, Productivity Perfected

Fueled by Intel® Core™ processor with up to Intel vPro® Enterprise, the ThinkCentre M90q Gen 5 Tiny PC delivers enterprise-grade performance, security, manageability, and reliability — managing businesses of all sizes while boosting productivity, creative output, and digital collaborations with vast memory, storage, and up to WiFi 7.

Workspace Efficiency Redefined

Connect to multiple peripherals via a hub of ports, and enable customization with optional expansion slots such as VGA / DisplayPort / HDMI® / Ethernet (RJ45) / USB-C®, etc. Charge your smartphone readily using the PowerShare USB, even with the PC powered off. Plus, multitask easily with support for up to four independent displays — the sky’s the limit.

Device Convenience Reimagined

With a keyboard shortcut to turn on the desktop, and a quick boot-up process via the Thunder Boot feature, this ThinkCentre PC reflects ease of convenience, making it the perfect choice for modern workspaces. Plus, with Modern Standby, your system remains up-to-date even during sleep mode, and it wakes and connects instantly.

Ultimate PC Security Enabled

Our ThinkShield security encrypts data via the discrete Trusted Platform Module (dTPM), while the self-healing BIOS restores earlier system settings. Secure your PC physically with the Kensington Security Slot™, and choose the Intel vPro® Enterprise platform for multilayer security like Intel® Hardware Shield to block cyberattacks and ransomware.

Effortless Upgrades, Easy Maintenance

Along with a sleek design, the ThinkCentre M90q Gen 5 Tiny desktop is also ready for toolless upgrades, saving IT valuable time. The removable easy-to-clean dust shield assists with upkeep to extend the lifecycle. Plus, an AI-driven fan prevents overheating issues — keeping the system cool and efficient for all-day-long operations.

Future Forward, Future Ready

The M90q Gen 5 uses 85% recycled post-consumer content acrylonitrile butadiene styrene plastics in the chassis. The packaging has 60% post-industry content (PIC), 30% ocean-bound plastic in the thermal shell and bag, and is certified by Forest Stewardship Council® (FSC). Plus, ENERGY STAR® 8.0 and TCO 9.0 ratings minimize energy costs.

• Intel Core i5-14500, 14C (6P + 8E)/20T, P-core 2.6/5.0GHz, E-core 1.9/3.7GHz, 24MB
• 1x 16GB SO-DIMM DDR5-4800
• 256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
• Intel UHD Graphics 770
• Windows 11 Pro

Processor family	Intel Core i5
Processor manufacturer	Intel
Processor model	i5-14500
Processor generation	Intel Core i5-14xxx
Processor cores	14
Processor threads	20
Processor boost frequency	5
Performance cores	6
Efficient cores	8
Performance-core Max Turbo Frequency	5
Efficient-core Max Turbo Frequency	3.7
Performance-core base frequency	2.6
Efficient-core base frequency	1.9
Processor cache	24
Processor cache type	Smart Cache
Number of processors installed	1
Processor base power	65
Maximum turbo power	154
Internal memory	16
Maximum internal memory	64
Internal memory type	DDR5-SDRAM
Memory layout (slots x size)	1 x 16
Memory slots	2x SO-DIMM
Memory clock speed	4800
Memory channels	Dual-channel
Total storage capacity	256
Optical drive type	N
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	256
Number of SSDs installed	1
SSD capacity	256
SSD interface	PCI Express 4.0
NVMe	Y
SSD form factor	M.2
Card reader integrated	N
Discrete graphics card	N
On-board graphics card	Y
Discrete graphics card model	Not available
On-board graphics card model	Intel UHD Graphics 770
On-board GPU manufacturer	Intel
On-board graphics card family	Intel UHD Graphics
Product type	Mini PC (<= 3L)
Market positioning	Everyday
Motherboard chipset	Intel Q670
Password protection	Y
Password protection type	BIOS,HDD,Power on,SSD,Supervisor
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Built-in speaker(s)	Y
Ethernet LAN	Y
Wi-Fi	Y
Ethernet LAN data rates	100,1000
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 6E AX211
Antenna type	2x2
Bluetooth	Y
Bluetooth version	5.3
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
HDMI ports quantity	1
USB 3.2 Gen 2x2 Type-C ports quantity	1
DisplayPorts quantity	2
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Y
Power supply	135
Chassis type	Mini PC
Product colour	Black
Colour name	Black
Volume	1
Placement supported	Horizontal/Vertical
Cable lock slot	Y
Cable lock slot type	Kensington
Operating system installed	Windows 11 Pro
Operating system language	ENG
Display included	N
Audio chip	Realtek ALC233
Audio system	High Definition Audio
Number of speakers	1
Operating temperature (T-T)	5 - 35
Storage temperature (T-T)	-40 - 60
Operating relative humidity (H-H)	20 - 80
Storage relative humidity (H-H)	10 - 90
Operating altitude	0 - 3048
Non-operating altitude	0 - 12192
Width	179
Depth	182.9
Height	36.5
Weight	1250
Package width	490
Package depth	128
Package height	250
Package weight	2848
Mouse included	Y
Mouse connectivity	Wired
Keyboard included	Y
Certification	ErP Lot 3 RoHS compliant TCO Certified 9.0 MIL-STD-810H
Keyboard connectivity	Wired
