Latest Intel® processor

Accomplish everything from minor tasks to complex projects with the latest Intel® processor.[2]

Flex ports for easy expansion

Configure or expand your Mini your way with flex ports for legacy or clean desk connectivity.

Protected by HP Wolf Security

HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense.[4]

Help protect our shared future

A high-efficiency power supply and molded-pulp packaging6 help reduce the impact on the environment.[6]

Connectivity and Communications
Wireless	Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card
Expansion slots	1 M.2 2230; 1 M.2 2280
Bluetooth version	Bluetooth® 5.2
Wireless antenna	2x2
Ports	1 headphone/microphone combo; 1 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed USB Type-A 10Gbps signaling rate (charging); 1 SuperSpeed USB Type-C® 20Gbps signaling rate
Wireless standard	Wi-Fi 6E
Wireless Model	Wi-Fi 6E AX211
Expansion slots note	1 M.2 slot for WLAN and 1 M.2 2280 slot for storage.
Wireless supplier	Intel®
I/O Port location	Rear
I/O Port location	Front
Ports	1 power connector; 1 RJ-45; 1 SuperSpeed USB Type-A 10Gbps signaling rate; 2 SuperSpeed USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; 1 HDMI 2.1
Network interface type	WLAN
Product Numbers
UNSPSC code	43211507
System Components
Form factor	Mini
Legal Information
Copyright notice	© Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Image legal disclaimer	Product image may differ from actual product
Processor
Processor maximum frequency uom	GHz
Processor threads	20
Chipset footnote number	[3]
Processor family	Core™ i5
Processor maximum frequency	4.8
Processor family	Intel® Core™ i5 14th generation processor
Processor	Intel® Core™ i5-14500T (up to 4.8 GHz Max Turbo frequency, 24 MB L3 cache, 14 cores, 20 threads)
Processor core	14
Processor cache	24 MB L3
Processor frequency technology	Intel® Turbo Boost Technology
Chipset	Intel® Q670 (vPro®)
Processor name footnote number	[6,7]
Processor generation	14th Generation
Processor Brand	Intel®
Processor model	14500T
Memory
Memory	16 GB DDR5-4800 MHz RAM (1 x 16 GB)
Memory Slots	2 DIMM
Memory layout (slots & size)	1 x 16 GB
Memory and storage	16 GB memory; 512 GB SSD storage
Memory size	16
Number of memory slots	1
Memory module type	SODIMM
Memory speed uom	MHz
Memory speed	4800
Standard memory note	Transfer rates up to 4800 MT/s.
Memory type	DDR5
Memory size uom	GB
Battery and Power
Power	90 W external power adapter, up to 89% efficiency, active PFC
Footnotes
Tech spec footnote	[1] Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows is automatically updated and enabled. High speed internet and Microsoft account required. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.
Tech spec footnote	[14] Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information.
Tech spec footnote	[26] HP BIOSphere Gen6 features may vary depending on the platform and configuration.
Tech spec footnote	[4] Multi-core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
Tech spec footnote	[18] myHP requires Windows OS.
Tech spec footnote	[11] The 2.5" SATA drive bay can be both HDD and SSD.
Tech spec footnote	[23] HP Sure Sense is available on select HP PCs with Windows 10 Pro, Windows 10 Enterprise, Windows 11 Pro, or Windows 11 Enterprise OS.
Tech spec footnote	[5] Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies depending on hardware, software and overall system configuration. See www.intel.com/technology/turboboost for more information.
Tech spec footnote	[13] Availability may vary by country(Antimicrobial China only)
Tech spec footnote	[25] HP Sure Admin requires Windows 10 or higher, HP BIOS, HP Manageability Integration Kit from http://www.hp.com/go/clientmanagement and HP Sure Admin Local Access Authenticator smartphone app from the Android or Apple store.
Tech spec footnote	[17] HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement .
Tech spec footnote	[10] This system is preinstalled with Windows 10 Pro software and also comes with a license for Windows 11 Pro software and provision for recovery software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.
Tech spec footnote	[3] For full Intel® vPro® functionality, Windows 10 Pro 64 bit, a vPro supported processor, vPro enabled chipset, vPro enabled wired LAN and/or WLAN card and TPM 2.0 are required. Some functionality requires additional 3rd party software in order to run. See http://intel.com/vpro
Tech spec footnote	[22] HP Sure Click requires Windows 10 Pro or higher or Enterprise. See https://bit.ly/2PrLT6A_SureClick for complete details.
Tech spec footnote	[7] Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See http://www.intel.com/technology/turboboost/ for more information.
Tech spec footnote	[32] Platform power consumption varies per configuration, for the best user experience, please connect PC power cord while using USB-C® cable via Super Speed USB Type-C® port in the rear side of the platform.
Tech spec footnote	[16] HP Patch Assistant available on select HP PCs with the HP Manageability Kit that are managed through Microsoft System Center Configuration Manager. HP Manageability Integration Kit can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html .
Tech spec footnote	[9] For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows) of disk is reserved for system recovery software.
Tech spec footnote	[31] Only 35 W processors are offered.
Tech spec footnote 56	[56] This product includes a one (1) year license of HP Wolf Pro Security Edition which includes HP Sure Click Pro and HP Sure Sense Pro. The HP Wolf Pro Security Edition software is licensed under the license terms of the HP End User License Agreement (EULA) that can be found at: https://support.hp.com/us-en/document/ish_3875769-3873014-16 as modified by the following: “7. Term. Unless otherwise terminated earlier pursuant to the terms contained in this EULA, the license for the HP Wolf Pro Security Edition (HP Sure Sense Pro and HP Sure Click Pro) is effective upon activation and will continue for twelve (12) months thereafter (“Initial Term”). At the end of the Initial Term you may either (a) purchase a renewal license for the HP Wolf Pro Security Edition from HP.com, HP Sales or an HP Channel Partner, or (b) continue using the standard versions of HP Sure Click and HP Sure Sense at no additional cost with no future software updates or HP Support.”
Tech spec footnote	[24] HP Sure Start Gen7 is available on select HP PCs and requires Windows 10 and higher.
Tech spec footnote	[21] HP Smart Support requires HP TechPulse to be installed. For more information about how to enable or to download HP Smart Support, please visit http://www.hp.com/smart-support .
Tech spec footnote	[2] This system is preinstalled with Windows 10 Pro software and also comes with a license for Windows 11 Pro software and provision for recovery software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.
Tech spec footnote	[28] Absolute firmware module is shipped turned off and can only be activated with the purchase a license subscription and full activation of the software agent. License subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. Certain conditions apply. For full details visit: https://www.absolute.com/about/legal/agreements/absolute/.
Tech spec footnote	[12] Ports are optional. Max of one Flex Port 1 can be configured, with Serial port sold separately or as an optional feature. Max of one Flex Port 2 can be configured, and must be configured at time of purchase.
Tech spec footnote	[30] Wi-Fi 6E requires a Wi-Fi 6E router, sold separately, to function in the 6GHz band. Availability of public wireless access points limited. Wi-Fi 6E is backwards compatible with prior 802.11 specs. And available in countries where Wi-Fi 6E is supported.
Tech spec footnote	[20] HP Support Assistant: Requires Windows and Internet access.
Tech spec footnote	[8] Actual data rate is determined by both the system's configured processor and memory module installed.
Tech spec footnote	[6] Multi-core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
Tech spec footnote	[27] For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel® Optane™.
Tech spec footnote	[15] HP Connect for Microsoft Endpoint Manager is available from the Azure Market Place for HP Pro, Elite, Z and Point-of-Sale PCs managed with Microsoft Endpoint Manager. Subscription to Microsoft Endpoint Manager required and sold separately. Network connection required.
Tech spec footnote	[19] Starting from November 1st 2023, all shipments will require Windows to be installed on SSD to provide users a better experience. HDD can only be configured as additional data drives and not the boot drive.
Tech spec footnote	[29] Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs.
Weights
Package weight	3.40 kg
Weight note (metric)	Exact weight depends on configuration.
Package weight note (metric)	Packaging material used will vary by Country
Weight	1.42 kg
Package weight	7.40 lb
Weight note (imperial)	Exact weight depends on configuration.
Package weight note (imperial)	Packaging material used will vary by Country
Weight	3.13 lb
Multimedia and Input Devices
Keyboard	HP Wired Desktop 320K Keyboard
Pointing device	HP 125 Wired Mouse
Keyboard interface	USB
Audio	Realtek ALC3252 codec, universal audio jack with CTIA and OMTP headset support
Software and Applications
Management features	HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Connect for Microsoft Endpoint Manager; HP Manageability Integration Kit (download); HP Patch Assistant (download)
Available software	HP Smart Support
Manageability features footnote number	[15,16,17]
Software included footnote number	[18,20]
Software included	HP Notifications; HP PC Hardware Diagnostics UEFI; HP Support Assistant; HP Connection Optimizer; HP Privacy Settings; HP PC Hardware Diagnostics Windows; HP Desktop Support Utilities; HP Easy Clean; Touchpoint Customizer for Commercial; HP Easy Clean Keyboard Driver; HSA Fusion for Commercial; HSA Telemetry for Commercial; HPX for CMIT
Available software footnote number	[21]
Certification and Compliance
Ecolabels	EPEAT® registered
Energy star certified	ENERGY STAR® certified
Microsoft
Legal tagline	HP recommends Windows 11 Pro for business
Datasheet Imagery
Datasheet photo 4	AHID/c8ad9625653a606773b3feb548ff8631879ccfb7
Datasheet photo 3	AHID/9344224886ffa85d098d6fbb80b4ea1b4a0cafbc
Datasheet photo 1	AHID/470e1cb93ade92344cce4e52c148d3bfb63f80ec
Datasheet photo 5	AHID/db3c1e6b1687731c3ec64ed825c434409e0aef6a
Environmental
Operating temperature range	10 to 35°C
Operating temperature range	50 to 95°F
Operating humidity range	10 to 90% RH
Warranty
Support service included	HP 1 Year Wolf Pro Security Edition Service. For terms and conditions, please visit https://h20195.www2.hp.com/v2/GetPDF.aspx/4AA8-1150ENW & https://www8.hp.com/h20195/v2/getpdf.aspx/4AA5-7123ENUS.pdf
Manufacturer Warranty	3 year (3/3/3) limited warranty includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
Supported Operating Systems
Operating system	Windows 11 Pro
Operating system footnote number	[1]
Playbook Icons
Playbook TS icon processor	https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png
Playbook TS icon weight imperial	http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png
Playbook TS icon weight metric	https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png
Playbook TS icon OS	http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png
Playbook TS icon connectivity	http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png
Playbook TS icon graphics	https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png
Playbook TS icon storage	http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png
Playbook TS icon dimensions tower	https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png
Playbook TS icon memory	https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png
Dimensions
Package dimensions (W x D x H)	19.61 x 9.25 x 5.20 in
Package dimensions (W x D x H)	49.8 x 23.5 x 13.2 cm
Package dimension note (imperial)	Packaging material used will vary by Country
Package dimension note (metric)	Packaging material used will vary by Country
Minimum dimensions (W x D x H)	17.7 x 17.5 x 3.4 cm
Minimum dimensions (W x D x H)	6.97 x 6.89 x 1.34 in
Barcodes
UPC number	198415636584
Security Management
Security management footnote number	[22,23,24,25,26,27,28]
Security management	Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); HP Secure Erase; HP Sure Click; HP Sure Sense; Absolute Persistence module; HP Sure Admin; HP BIOSphere Gen6; HP Tamper Lock; HP Sure Start Gen7; HP Platform Certificate On Device Installation
Security software licenses footnote number	[56]
Security Software Licenses	HP Wolf Pro Security Edition (1 year)
Drives and Storage Specifications
Storage interface protocol 01	NVMe™
Storage capacity	512
Internal Storage	512 GB PCIe® Gen4 NVMe™ TLC M.2 SSD
Storage type 01	SSD
Internal drive bays	One 2.5"
Storage interface 01	PCIe® Gen 4
Storage type	SSD
Drive bays footnote number	[11]
Storage memory technology 01	TLC
Storage capacity uom 01	GB
Information Pointers
Additional information about HP in the countries	hp.com
Graphic Subsystem
Graphics (integrated)	Intel® UHD Graphics 770
Graphics	Integrated
Product Names
Product long name specifications	HP Pro Mini 400 G9 Desktop PC, Windows 11 Pro, Intel® Core™ i5, 16GB RAM, 512GB SSD
Product short name specifications	HP Pro Mini 400 G9 Desktop PC, Intel® Core™ i5, 16GB RAM, 512GB SSD
