APC Back-UPS ES 650 Battery Backup System, 8 Outlets, 650 VA, 340 J - BE650G1

Features

• Energy-efficient design.

• Data line surge protection.

• Four stage LED status display.

• Audible alarms.

• Transformer-block spaced outlets.

• Designed to use less energy during normal operation, this backup system provides enough power for you to work through short and medium length power outages. Data line protection safeguards your equipment from damaging surges and spikes that travel along utility and data lines. Four stage LED status display indicates On Line, On Battery, Replace Battery and Building Wiring Fault conditions. Continuous tone and two different chime alerts notify you of changing utility power and UPS conditions. Wide spaced outlets allow you to protect equipment that uses input transformer blocks without blocking access to other receptacles.

• Designed to use less energy during normal operation, this backup system provides enough power for you to work through short and medium length power outages. Data line protection safeguards your equipment from damaging surges and spikes that travel along utility and data lines. Four stage LED status display indicates On Line, On Battery, Replace Battery and Building Wiring Fault conditions. Continuous tone and two different chime alerts notify you of changing utility power and UPS conditions. Wide spaced outlets allow you to protect equipment that uses input transformer blocks without blocking access to other receptacles.

• Designed to use less energy during normal operation, this backup system provides enough power for you to work through short and medium length power outages. Data line protection safeguards your equipment from damaging surges and spikes that travel along utility and data lines. Four stage LED status display indicates On Line, On Battery, Replace Battery and Building Wiring Fault conditions. Continuous tone and two different chime alerts notify you of changing utility power and UPS conditions. Wide spaced outlets allow you to protect equipment that uses input transformer blocks without blocking access to other receptacles.

• Reliable backup power.

• Protection from surges and spikes.

• Automatic battery self-test.

• Hot-swappable batteries.

• Audible alarms.

• Protect computers and other sensitive electronics with reliable backup power. Power conditioning protects connected loads from surges, spikes, lightning, and other disturbances. Automatic battery self-test ensures early detection of a battery that needs to be replaced. Hot-swappable batteries deliver clean, uninterrupted power to protected equipment while batteries are being replaced. Audible alarms provide notification of changing utility power and UPS conditions. Combination of battery-protected and surge-only outlets reserves power capacity for connected equipment that requires battery back-up.

•

---

Specification

Global Product Type	Backup Systems
Protection Type	Cable Modem
Protection Type	DSL
Protection Type	Ethernet
Protection Type	Fax
Protection Type	Modem
Protection Type	Phone
Protection Type	Power
System VA	650 VA
Backup Time at Half Load	13.4 min @ 195 W
Lines	1
Automatic Voltage Regulation (AVR)	Yes
Multimedia Protection	Ethernet/Telephone/Modem
Battery Recharge Time	16 h
Connected Equipment Guarantee/Warranty	$75,000 Equipment Protection Policy
Backup Time at Full Load	3.8 min @ 390 W
Jacks/Ports	RJ11
Connector/Port/Interface	Coaxial
Connector/Port/Interface	RJ11
Connector/Port/Interface	RJ45
Connector/Port/Interface	USB
Joules Of Surge Protection	340 J
Number of Outlets	8
Diagnostics/Alarm/Status Light	Alarm
Diagnostics/Alarm/Status Light	LED
React Time	Instantaneous
Cord Length	5 ft
Telephone/Internet Protection	Cable
Telephone/Internet Protection	DSL
Telephone/Internet Protection	Ethernet
Telephone/Internet Protection	Fax
Telephone/Internet Protection	Phone
Color(s)	Charcoal
Width	12.6
Height	3.6
Depth	7
Backup Systems Alarm(s)	Audible
Emergency Power Off (EPO)	No
Input Frequency	60 Hz
Model Name/Number	Back-UPS ES 650
Number of Outlets/Type	4 UPS/Surge
Number of Outlets/Type	4 Surge Only
Weight	14.3 lbs
Backup Run Time	13 min
Product Biodegradability Indicator	N
Product Compostability Indicator	N
Compliance Standards	Conforms to UL 1449 Standards
Compliance Standards	Conforms to UL 1778 Standards
Compliance Standards	FCC Class B Certified
Compliance Standards	FCC Part 68 Certified
Compliance Standards	TUV SUD Certified
Pre-Consumer Recycled Content Percent	0%
Post-Consumer Recycled Content Percent	0%
Total Recycled Content Percent	0%
Disclaimer Statement	Run Time based on a load of 195 W.
Special Features	Includes PowerChute® Auto-Shutdown Software

---
