TP-Link Omada SG5428X network switch Managed L3 Gigabit Ethernet (10/100/1000) Black - SG5428X

What This Product Does
Omada SG5428X is a dependable entry-level L3 switch tailored for the access layer, featuring L3 routing, fast 10 Gbps wired speeds, and stacking options. It includes 24× gigabit RJ45 ports, 4× 10 Gbps SFP+ slots, physical stacking ability, and centralized management. Integrated with strong security and extensive management features, the SG5428X offers a reliable networking solution for SMEs, and ISPs.

High-speed Connectivity and Powerful Stacking
24× gigabit RJ45 ports and 4× 10 Gbps SFP+ slots provide up to 128 Gbps switching capacity per unit. Up to 4 units of physical stacking empower the networking structure with built-in redundancy and performance.

Abundant Layer 3 Capabilities
Comes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, DHCP Server, and DHCP Relay are supported.

Highly Available
ERPS (Ethernet Ring Protection Switching) ensures rapid protection and recovery in ring topologies, which is essential for maintaining network uptime in medium business environments.

Enhanced Security Functions
Defend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.

Omada SDN
Integration into the Omada system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP).† The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and gateways, providing 100% centralized cloud management—all controlled from a single interface.

Apart from the ability to be centrally managed via the web or the Omada app, SG5428X is also easy to manage via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events.

• 24× Gigabit RJ45 ports and 4× 10 Gbps SFP+ slots
• 128 Gbps switching capacity per unit
• Physical stacking up to 4 units for built-in redundancy and performance
• L3 features: RIP, OSPF, Static Routing, and DHCP Server/Relay
• Security strategies: ACL, Port Security, DoS Defend, 802.1X
• ERPS supports rapid protection and recovery in a ring topology
• Centralized cloud management via the Omada SDN controller
• Standalone management via web, CLI, SNMP, and RMON

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
Web-based management	Y
Cloud-managed	Y
ARP inspection	Y
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Gigabit Ethernet (copper) ports quantity	24
SFP+ module slots quantity	4
USB Type-C ports quantity	1
Console port	RJ-45
USB 2.0 ports quantity	1
Networking standards	IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt
10G support	Y
Port mirroring	Y
Link aggregation	Y
Broadcast storm control	Y
VLAN support	Y
Virtual LAN features	MAC address-based VLAN,Private VLAN,Protocol-based VLAN,Voice VLAN
Number of VLANs	4000
MAC address table	16000
Switching capacity	128
Forwarding rate	95.23
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	12
DHCP features	DHCP relay,DHCP server
Access Control List (ACL)	Y
IGMP snooping	Y
Security algorithms	SNMP,SNMPv2,SNMPv3
MAC address filtering	Y
Static port security	Y
SSH/SSL support	Y
IP-MAC-Port binding	Y
Password protection	Y
Multicast support	Y
Rack mounting	Y
Stackable	Y
Product colour	Black
LED indicators	Y
Physical stacking (units)	4
Built-in processor	Y
Processor manufacturer	ARM
Processor frequency	1200
Memory type	DRAM
Internal memory	2000
Flash memory	512
Firmware upgradeable	Y
Telnet	Y
Fanless	Y
Mean time between failures (MTBF)	519.543
Power source	AC
Power supply included	Y
AC input voltage	100 - 240
AC input frequency	50/60
Power consumption (max)	19.6
Surge protection	Y
Surge protection voltage	6
Power over Ethernet (PoE)	N
Management level	4
Bandwidth	64
Operating temperature (T-T)	-5 - 45
Storage temperature (T-T)	-40 - 70
Operating relative humidity (H-H)	10 - 90
Storage relative humidity (H-H)	5 - 90
Heat dissipation	66.87
Width	440
Depth	180
Height	44
Cables included	AC
Quick start guide	Y
Rack mount kit	Y
Compliance certificates	CE,Federal Communications Commission (FCC),RoHS
