Yealink UVC40 E2 video conferencing system 8 MP Personal video conferencing system - 1206673

VC40 E2
Smarter Meetings, One Device.
All-in-One Intelligent USB Conference Camera for Small and Huddle Rooms

MAKE YOUR MEETINGS SMARTER

With 4K ultra-HD imaging, a 120° super-wide-angle lens and Smart Area Exposure technology, the UVC40 E2 ensures exceptional video quality. AI features like Auto Framing and Speaker Tracking enhance conferencing, while 8 MEMS microphones and a high-fidelity speaker ensure excellent call quality. Manageable via Yealink Device Management Platform, UVC40 E2 is your choice for seamless collaboration.

SMART AI, CLEAR FOCUS.

With advanced AI technology such as Auto Framing and Speaker Tracking, the UVC40 E2 automatically adjusts framing based on participant count and positions, seamlessly zooms in on speakers without manual intervention, ensuring enhanced conference focus during meetings.

SMART VISION, WIDE VIEW.

Featuring a ultra-HD 4K lens, the UVC40 E2 ensures clear and smooth video calls, delivering vivid and detailed presentations. Its 120° ultra-wide view effortlessly covers every corner of the meeting room, capturing all participants. Smart Area Exposure* enhances overall brightness through AI image algorithms, ensuring optimal face and picture presentation.

Smart Sound,
Superior Clarity.
8 MEMS microphone arrays for superior noise reduction and echo cancellation. Enhanced by an upgraded beamforming algorithm and advanced acoustic processing technology, the UVC40 E2 delivers high-quality full-duplex calls with precise voice pickup.

• All-in-One Intelligent USB Video Bar
• Plug-and-play

Product type	Personal video conferencing system
Product colour	Black
Number of cameras	1
Auto framing	Y
Signal-to-Noise Ratio (SNR)	72
HD type	4K Ultra HD
Maximum frame rate	30
Built-in speaker(s)	Y
Frequency range	50 - 20000
Audio system full duplex	Y
Line-out impedance	4
Noise reduction	Y
Echo cancellation	Y
Automatic gain control	Y
Audio Lip synchronization	Y
Speaker power	5
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	1
DC-in jack	Y
Microphone in	Y
Reset slot	Y
Wi-Fi	Y
Megapixel (approx.)	8
Sensor type	CMOS
Image sensor size	1/1.8
Camera type	Single camera
Field of view (FOV) angle	120
Microphone sensitivity	-38
Number of microphones	8
Number of microphone arrays	1
Cable lock slot	Y
Country of origin	China
Windows operating systems supported	Y
Mac operating systems supported	Y
Operating temperature (T-T)	0 - 40
Operating relative humidity (H-H)	10 - 95
Storage temperature (T-T)	-30 - 70
Power source type	AC
AC input voltage	100 - 240
DC output voltage	48
DC output current	0.7
Width	600
Depth	68
Height	82
Weight	13000
Package width	685
Package depth	397
Package height	290
Package weight	13060
Cables included	USB
AC adapter included	Y
Mounting kit	Y
Remote control included	Y
Quick start guide	Y
