APC SMT2200RM2UC uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1980 W 8 AC outlet(s) - SMT2200RM2UC

Reliable Backup Power and Protection for Your Valuable IT Equipment

Protect your servers, switches, routers and networking devices while providing battery backup power with Smart-UPS SMT2200RM2UC with APC SmartConnect, the first cloud-enabled UPS for distributed IT. The service-free cloud monitoring feature is accessible from any internet-connected device, and maximizes the life and performance of your UPS by providing proactive advice and life-cycle recommendations so you can remotely monitor your power infrastructure from anywhere.

An Overview of Smart-UPS and the SmartConnect App

APC SmartConnect makes Smart-UPS more adaptable and easier to deploy than ever before, enabling you to view the status of your UPS through a secure web portal. Through this intuitive remote management interface, you’ll receive automatic notifications, firmware updates, and advanced support; providing you with added value – and more importantly – added peace of mind.

Secure, remote monitoring

Connected Smart-UPS support remote monitoring through a secure web portal, so you can always be up to date on the status of your power infrastructure.

Proactive lifecycle alerts

Maximize the life span of the UPS and protect your investment with proactive alerts for firmware upgrade, device maintenance, and warranty protection.

Cloud enabled as standard

Smart-UPS models with SmartConnect are cloud-enabled and have a built-in Ethernet port, making it easy and cost effective to monitor your UPS online.

Simple to Use Interface

Our simple web interface is designed to support both system administrators and non-tech users alike, with clear notifications in plain language.

• Line-Interactive
• 2.2 kVA 1980 W
• Waveform: Sine
• 8 AC outlet(s)
• Sealed Lead Acid (VRLA)
• Rackmount Black

UPS topology	Line-Interactive
Output power capacity	2.2
Output power	1980
Waveform	Sine
Input operation voltage (min)	75
Input operation voltage (max)	154
Input frequency	50/60
Output operation voltage (min)	110
Output operation voltage (max)	127
Output frequency	50/60
Automatic Voltage Regulation (AVR)	Y
Surge energy rating	530
Emergency Power Off (EPO)	Y
Output voltage Total Harmonic Distortion (THD)	5
Noise level	55
Audible alarm(s)	Y
Web-based management	Y
Audible alarm modes	Alarm when on battery,Low battery alarm,Overload alarm
Temperature voltage compensation	Y
AC outlet types	NEMA 5-15R,NEMA 5–20R
Power plug	NEMA 5-20P
AC outlets quantity	8
USB port	Y
Serial interface	Y
Serial interface type	RJ-45
Ethernet LAN (RJ-45) ports	1
SmartSlot	Y
Battery technology	Sealed Lead Acid (VRLA)
Number of batteries supported	1
Battery life (max)	5
Battery recharge time	3
Hot-swap battery	Y
Automatic battery test	Y
Cold start	Y
Form factor	Rackmount
Product colour	Black
Rack capacity	2U
Cable length	2.44
Display type	LCD
LED indicators	Status
Operating temperature (T-T)	0 - 40
Storage temperature (T-T)	-15 - 45
Operating relative humidity (H-H)	0 - 95
Storage relative humidity (H-H)	0 - 95
Operating altitude	0 - 3000
Non-operating altitude	0 - 15000
Certification	CSA, FCC, UL
Sustainability certificates	ENERGY STAR
Width	480
Depth	683
Height	86
Weight	43210
Package width	600
Package depth	980
Package height	254
Package weight	49730
Products per pallet	8
