ASUS PRIME H810M-A WIFI-CSM Intel H810 LGA 1851 (Socket V1) micro ATX - PRIME H810M-A WIFI-CSM

Prime H810M-A WIFI-CSM
ASUS PRIME series motherboards are expertly engineered to unleash the full potential of the latest Intel® Core™ Ultra Processors (Series 2). Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, the PRIME H810M-A WIFI-CSM motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.

• Intel LGA 1851 (Socket V1) Intel Core Ultra (Series 2)
• PC micro ATX Intel H810 7.1 channels
• DDR5-SDRAM 2 DIMM Maximum internal memory: 128 GB
• HDD & SSD M.2, SATA III Number of storage drives supported: 6
• BIOS type: UEFI AMI 256 Mbit
• Gigabit Ethernet Wi-Fi Wi-Fi 6 (802.11ax) Bluetooth 5.3

Processor manufacturer	Intel
Processor socket	LGA 1851 (Socket V1)
Compatible processor series	Intel Core Ultra (Series 2)
Supported memory types	DDR5-SDRAM
Number of memory slots	2
Maximum internal memory	128
Memory slots type	DIMM
Memory channels	Dual-channel
ECC сompatibility	non-ECC
Supported memory clock speed (max)	6400
Unbuffered memory	Y
Supported storage drive interfaces	M.2,SATA III
Supported storage drive types	HDD & SSD
Number of HDDs supported	4
Number of storage drives supported	6
Parallel processing technology support	Not supported
USB 2.0 connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA III connectors	4
S/PDIF out connector	Y
Front panel audio connector	Y
ATX Power connector (24-pin)	Y
CPU fan connector	Y
Number of CPU fan connectors	1
Number of chassis fan connectors	2
EPS power connector (8-pin)	Y
TPM connector	Y
12V power connector	Y
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
HDMI ports quantity	1
DVI-D ports quantity	0
PS/2 ports quantity	1
DisplayPorts quantity	1
Microphone in	Y
Wi-Fi	Y
Ethernet LAN	Y
Ethernet interface type	Gigabit Ethernet
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Bluetooth	Y
Bluetooth version	5.3
Component for	PC
Motherboard form factor	Micro ATX
Motherboard chipset family	Intel
Motherboard chipset	Intel H810
Audio output channels	7.1
Product colour	Multicolour
Windows operating systems supported	Windows 10 x64,Windows 11
PCI Express x1 (Gen 4.x) slots	1
Number of M.2 (M) slots	2
BIOS type	UEFI AMI
BIOS memory size	256
Width	244
Depth	222
