Sharp MultiSync M862 Digital signage flat panel 2.18 m (86") LCD 550 cd/m² 4K Ultra HD Black 24/7 - PN-M862

Built to perform, designed to last
The versatile solution for professional display applications, the Sharp MultiSync® M2 Series (32" up to 98") is purpose-built for demanding signage and meeting room environments. With native USB-C connectivity and broad compatibility with platforms such as Crestron, Cisco Webex, and Microsoft Teams, it enables seamless BYOD collaboration and future-ready integration, while 802.1x LAN support ensures enterprise-grade network security. Featuring class-leading 550 cd/m² brightness, a high-haze panel to minimise glare, and NEC’s trusted SpectraView Engine, the M2 Series delivers outstanding visual performance with unmatched colour precision.

As part of the new Sharp-branded display family, the MultiSync® M2 Series builds on NEC’s legacy of quality and reliability to drive greater efficiency and long-term value. Its proven modular design supports custom computing options (Raspberry Pi or Intel® SDM) and flexible connectivity (e.g. AV-over-IP), ensuring lasting versatility, performance, and sustainability.

• Seamless meeting workflows – a single USB-C cable transmits video, data, and power for instant, clutter-free meeting setups. As the established standard for modern collaboration spaces, USB-C supports frictionless BYOD experiences
• Unhindered readability – a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment
• Security assured – 802.1x support over LAN enables high-level security for corporate networks, giving peace of mind for IT teams and enterprise environments
• Enhanced imaging precision – when brand consistency and corporate identity are important, NEC’s SpectraView Engine provides full control over colour, gamma, and uniformity for accurate and impactful content
• Broad AV compatibility – fully interoperable with leading meeting room platforms including Crestron (XiO Cloud), Cisco Webex, Q-Sys, and Microsoft Teams, ensuring effortless integration and future-proof scalability

Display diagonal	86
Display technology	LCD
Display resolution	3840 x 2160
Display brightness	550
HD type	4K Ultra HD
Touchscreen	N
Panel type	IPS
LED backlight	Y
LED backlighting type	Direct-LED
Native aspect ratio	16:9
Response time	8
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178
Viewing angle, vertical	178
Display number of colours	1.073 billion colours
Display diagonal (metric)	217.2
Horizontal scan range	15 - 135
Vertical scan range	23 - 76
High Dynamic Range (HDR) supported	Y
Native refresh rate	60
RGB colour space	NTSC
HDMI ports quantity	3
DVI port	N
DisplayPorts quantity	2
USB port	Y
HDMI input ports quantity	2
HDMI output ports quantity	1
DisplayPorts in	1
DisplayPorts out	1
DisplayPort version	1.2
USB ports quantity	4
USB connector type	USB Type-A,USB Type-C
USB Type-C DisplayPort Alternate Mode	Y
Ethernet LAN (RJ-45) ports	2
RS-232C	Y
Remote (IR) input	1
Audio Return Channel (ARC)	Y
Built-in speaker(s)	Y
Number of built-in speakers	2
RMS rated power	20
Product design	Digital signage flat panel
Product colour	Black
Placement supported	Indoor
VESA mounting	Y
Orientation	Horizontal/Vertical
Screen shape	Flat screen
Panel mounting interface	600 x 400
Bezel width (bottom)	14.8
Bezel width (side)	14.3
Bezel width (top)	14.3
Mounting type	Wall
Purpose	Universal
Operating hours (hours/days)	24/7
HDCP	Y
HDCP version	2.2
Power consumption (standby)	0.5
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	189
Energy consumption (HDR) per 1000 hours	167
AC input voltage	100 - 240
AC input frequency	50/60
Energy efficiency scale	A to G
Display width	1927.6
Display depth	83.2
Display height	1099.1
Display weight	47000
Package width	2090
Package depth	225
Package height	1225
Package weight	64000
Remote control included	Y
Batteries included	Y
Cables included	AC,HDMI
Operating temperature (T-T)	0 - 40
Operating relative humidity (H-H)	20 - 80
Storage temperature (T-T)	-20 - 60
Storage relative humidity (H-H)	-20 - 60
Ambient light sensor	Y
Eco sensor	Y
Ethernet LAN	Y
Ethernet LAN data rates	100
Sustainability certificates	ENERGY STAR
Compliance certificates	CE,Electromagnetic Compatibility (EMC),Federal Communications Commission (FCC),REACH,RoHS,UKCA,UL
Headphone connectivity	3.5 mm
Headphone outputs	1
