TP-Link Omada EAP725-Outdoor 5000 Mbit/s White Power over Ethernet (PoE) - EAP725-OUTDOOR

Versatile Antennas Deployment
Adapt to any environment effortlessly by selecting the antenna type that suits your needs. Whether you require long-distance connectivity or need to cover multiple endpoints, easily switch between external omni, internal directional, or custom antenna configurations with just a few clicks in the software.

Auto-Sensing Plug & Play—No Expertise Needed
Automatically detects the attachment and removal of antennas (included) in auto mode and seamlessly switches between the internal and external antennas with zero configuration.

Outdoor-Ready IP66 Weatherproof Design
The EAP725-Outdoor features an IP66 weatherproof rating, ensuring reliable protection against heavy rain, dust, and harsh weather conditions.

Seamless Connectivity with Mesh and Roaming
Ensures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.

Works with Omada SDN for One-Click Setup
Omada SDN allows users to quickly set up the EAP725-Outdoor through automatic device identification and one‑click adoption.

Empowering Businesses with Reliable Omada SDN Solutions
Omada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.

• Directional and Omnidirectional Antennas: Freely switch between modes via software for optimal signal control
• Plug & Play Auto-Sensing Antennas: Automatically detects antenna changes and switches between internal and external antennas as needed
• 4-Stream Dual-Band Wi-Fi 7: Up to 5.0 Gbps
• 1× 2.5G PoE Port: Flexible PoE deployment reduces costs by delivering power and data over a single Ethernet cable
• Outdoor-Ready Durability: Features an IP66-rated weatherproof enclosure and 6kV lightning protection
• Quick and Easy Setup: Features wall/pole mounting with Omada SDN for one-click setup
• Advanced Features: Centralized management, mesh, and seamless roaming

2.4 GHz	Y
5 GHz	Y
6 GHz	N
Maximum data transfer rate	5000
Maximum data transfer rate (2.4 GHz)	688
Maximum data transfer rate (5 GHz)	4324
Ethernet LAN data rates	10,100,1000,2500
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11be,IEEE 802.11g,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11v,IEEE 802.1x,IEEE 802.3at
Cabling technology	10/100/1000/2500Base-T
Bluetooth	Y
Bluetooth version	5.2
Bluetooth Low Energy (BLE)	Y
Wi-Fi Multimedia (WMM)/(WME)	Y
VLAN support	Y
Virtual LAN features	Management VLAN
Rate limiting	Y
Wireless isolation	Y
Band steering	Y
Quality of Service (QoS) support	Y
BeamForming	Y
Security algorithms	OWE,SNMP,SNMPv2,SNMPv3,SSH,WPA-Enterprise,WPA-Personal,WPA2-Enterprise,WPA2-Personal,WPA3-Enterprise,WPA3-Personal
MAC address filtering	Y
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	16
Schedule access	Y
Web-based management	Y
Syslog	Y
Cloud-managed	Y
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) type supported	PoE+
Power consumption (max)	18.4
Placement	Pole,Wall
Product colour	White
International Protection (IP) code	IP66
Reset button	Y
LED indicators	Status
Antenna type	Internal & External
Antennas quantity	8
Antenna gain level (max)	13.2
Compliance certificates	BSMI,CE,Federal Communications Commission (FCC),Industry Canada (IC),JRF,NCC,RoHS,VCCI
Width	208
Depth	160
Height	55
Weight	1330
Quantity per pack	1
Mounting kit	Y
Operating relative humidity (H-H)	10 - 90
Operating temperature (T-T)	-30 - 70
Storage temperature (T-T)	-40 - 70
Storage relative humidity (H-H)	5 - 90
